#explainer
Entry angle determines how quickly a spacecraft reaches denser air and how braking and heating are distributed. An overly steep entry can produce unacceptable acceleration and heat flux. An overly shallow entry can cause insufficient braking or a return above the atmosphere.
The entry corridor
Navigation must deliver the vehicle within an acceptable range of position and velocity. This corridor depends on design, available lift and entry speed. Orientation control can influence descent and the landing region. There is no single universally safe angle for every spacecraft.
A skip can be intentional
Some entry profiles use a controlled skip into thinner air to distribute loads and extend range. That differs from unintentionally missing the entry corridor. Safety requires matching the trajectory, heat shield and control system; simply choosing a shallow path does not guarantee protection.
Why corrections happen before entry
A small velocity change made early enough can alter the location and conditions of later entry. Navigation teams therefore assess the trajectory and plan corrections before major braking. Once the vehicle reaches denser air, available control and rapidly changing conditions limit the options. Trajectory accuracy and heat-shield capability work together.
Follow us
Follow us on social media
New plates, trivia and behind-the-scenes updates as soon as they are ready.
Key points
- Navigation must deliver the vehicle within an acceptable range of position and velocity.
- Some entry profiles use a controlled skip into thinner air to distribute loads and extend range.
- A small velocity change made early enough can alter the location and conditions of later entry.
Sources & further reading
- Entry aerothermodynamics and thermal-protection design.
- Behaviour and analysis of ablative heat-shield materials.
- Relationship between entry angle, deceleration and safe return.
